32路TTL電平DIO通道(16路輸入和16路輸出)
高輸出驅動能力
中斷能力
2個20針接口用于隔離數字量I/O通道,2個接口用于TTL數字量I/O通道
用于隔離輸入和輸出通道的D型接口
產品規格
PCI-1730U-BE | |
功耗 | 正常:5 V @ 250 mA, 12 V @ 35 mA, Max.: 5 V @ 400 mA |
OS支持 | 32-bit/64-bit Windows 7/8/10, and Linux |
尺寸 | 175 mm x 100 mm (6.9" x 3.9") |
接口 | PCI |
I/O接口 | 37-pin D-Sub female,20-pin insulation displacement connectors |
操作溫度 | 0 ~ 60°C (32 ~ 140°F) |
程序設計語言 | C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt |
TTL DI/O | |
輸入通道 | 16 |
輸入范圍 | 5 ~ 30 VDC |
輸出通道 | 16 |
輸出范圍 | 5 ~ 40 VDC |
可選配置
1、PCI-1730U:32-ch Isolated Digital I/O Univ. PCI Card
2、PCI-1733:32-ch Isolated Digital Input PCI Card
3、PCI-1734:32-ch Isolated Digital Output PCI Card
附件
1、PCL-10120-1E :20-pin Flat Cable, 1 m
2、ADAM-3920 :20-pin DIN-rail Flat Cable Wiring Board
3、PCLD-782:16-ch Isolated DI Board w/ 1m 20-pin Flat Cable
4、PCLD-885:16-ch Power Relay Board w/ 20p & 50p Flat Cables
5、PCLD-785:16-ch Relay Board w/ One 1m 20-pin Flat Cable
6、ADAM-3937:DB37 DIN-rail Wiring Board
7、PCL-10137-1E:DB37 Cable, 1 m
8、PCL-10137-2E:DB37 Cable, 2 m
9、PCL-10137-3E:DB37 Cable, 3 m
